Large-Scale Cooling for Big Mines
The Downhole Central Cooling Station Unit is a large-scale cooling station installed underground. It produces chilled water at a central location, which is then distributed through pipelines to all cooling points.
This centralized approach provides high efficiency and large cooling capacity. It is widely used as the mainstream solution for large and deep mining operations. The total station cooling capacity ranges from 2,000 kW to 10,000 kW. The equipment is a heavy-duty cooling solution for large mines.
Impressive Parameters
The single-unit capacity ranges from 500 kW to 2,000 kW. The system COP is above 3.5. The chilled water supply temperature ranges from 3℃ to 5℃.
The chilled water transport distance can reach up to 3,000 meters. The pipeline system uses high-density polyethylene (HDPE) insulated pipes. Control is managed through a DCS centralized monitoring system. The Downhole Central Cooling Station Unit is suitable for large-scale centralized cooling in deep mining environments.
Key Advantages and High Efficiency
The key advantage of an underground centralized cooling station is high efficiency. Large-scale units typically achieve higher energy efficiency compared to multiple small units. System management is also simplified, as all equipment can be controlled from a single control room.
We have been in business since 1996 and have extensive experience in centralized cooling systems. We have built cooling stations for many large deep mining projects, including operations at depths exceeding 1,000 meters.
Our DCS monitoring system can be integrated with mine dispatch centers, enabling centralized and convenient management. The Downhole Central Cooling Station Unit is a professional solution for large-scale mining operations.
Technical Data
|
Item |
Parameter |
|
Total Station Cooling Capacity |
2,000 kW – 10,000 kW |
|
Single Unit Capacity |
500 kW – 2,000 kW |
|
Cooling COP |
≥3.5 |
|
Chilled Water Supply Temperature |
3℃ – 5℃ |
|
Transport Distance |
Up to 3,000 m |
|
Pipeline Type |
HDPE Insulated Pipe |
|
Control Method |
DCS Centralized Monitoring |
|
Application |
Large-Scale Deep Mine Cooling |
Warranty and Support
- This system comes with a 12-month warranty. We provide full solution design services, including cooling station layout, equipment selection, and pipeline engineering design.
- We supply all equipment and provide detailed design drawings and installation specifications. After-sales support includes remote commissioning guidance.
- Our DCS system can be integrated with existing mine dispatch platforms. For overseas projects, we provide English-language software interfaces and complete technical documentation.
