Decentralized Cooling for Flexible Operation
The Split-type Underground Mining Cooling Device adopts a distributed cooling approach. Small cooling units are installed directly at each location requiring cooling, eliminating the need for long-distance chilled water pipelines.
This significantly reduces cooling loss and improves system flexibility. The solution also supports phased installation and expansion. The single-unit cooling capacity ranges from 10 kW to 100 kW. The equipment provides maximum flexibility for mining cooling applications.
Flexible Parameters
The main application areas include mining faces and electrical chambers. The air supply temperature ranges from 16℃ to 20℃. The air volume ranges from 1,000 to 10,000 cubic meters per hour.
The power supply is 380V or 660V. Installation options include both mobile and fixed types. The cooling method can be water-cooled or evaporative cooling. The Split-type Underground Mining Cooling Device is adaptable to various site conditions.
Key Advantages and Zero Cooling Loss
The key advantage of distributed cooling is the elimination of long-distance chilled water transportation. Traditional pipeline systems require high-quality insulation, and cooling losses can be significant over distance.
In contrast, the distributed system places cooling units directly at the point of use, making cooling loss nearly zero. The system also supports phased investment-users can start with a small number of units and expand as needed.
We have been in business since 1996 and have extensive experience in mining cooling systems. We have designed distributed cooling solutions for multiple mining projects, and customers appreciate the flexibility and ease of deployment.
The Split-type Underground Mining Cooling Device is a practical and scalable solution for evolving mining operations.
Technical Data
|
Item |
Parameter |
|
Single Unit Cooling Capacity |
10 kW – 100 kW |
|
Application Areas |
Mining Faces, Electrical Chambers |
|
Air Supply Temperature |
16℃ – 20℃ |
|
Air Volume |
1,000 – 10,000 m³/h |
|
Power Supply |
380V / 660V |
|
Installation Type |
Mobile / Fixed |
|
Cooling Method |
Water-cooled / Evaporative Cooling |
Warranty and Support
- This device comes with a 12-month warranty. We support single-unit orders and provide remote system design services.
- Simply share your site conditions, and we will design an optimized distributed cooling layout for you. After-sales support includes remote technical assistance.
- Phased delivery is supported-customers may start with a small number of units for testing and expand later based on performance. All equipment is packaged according to export standards.
